    Scotsman ECM57 Self Contained Ice Machine 32kg
1 1

Scotsman

Scotsman ECM57 Self Contained Ice Machine 32kg

Scotsman ECM57 Self Contained Ice Machine 32kg

REFERENCE:  ECM57 AS, 230/50/1 OX

Layer copy 8,662 (VAT Incl.)
Layer copy 8,662 (VAT Incl.) Layer copy (VAT Incl.)
Split your payment with Tabby or Tamara

Split your payment with Tabby or Tamara

Out of Stock

Last 1 items left!

Shipping policy

Delivery

Deliver to: Note: Timing may be affected if you miss a message from the courier. Add at least one item to change location.

Resources & Downloads

SPECIFICATIONS (PDF)

Fast Shipping
Trusted Brand
WhatsApp Support
Secure Pay

Question about our gear?

Our specialists know every detail. Get expert advice in seconds.

Chat: +971 52 438 5156 Call: +971 4 232 5554

Instant Gear Support

AI-assisted help for quick answers

Human Team Available

For complex product questions

Available

8:30 AM - 6:00 PM

Promos & Offers Available

View full details

Product Overview

Ice Production ·   Produces individual gourmet crystal-clear super cubes   Construction & Durability ·   Durable stainless steel exterior ·   Simple and reliable electromechanical controls   Cooling & Ventilation ·   Front-panel intake and exhaust airflow (air-cooled models only) ·   Suitable for built-in installation · . . .

read more
read less

Specifications & Details

Cooling System

·   Condensing System: Air-Cooled / Water-Cooled

·   Refrigerant Gas: R290



Electrical Specifications

·   Voltage / Frequency / Phase: 230–240 V / 50 Hz / 1 Phase

·   Electrical Voltage Tolerance: -10% / +10%



Operating Conditions

Air Temperature

·   Minimum: 10°C

·   Maximum: 43°C

Water Temperature

·   Minimum: 5°C

·   Maximum: 38°C

Water Pressure

·   Minimum: 1 bar (14 psi)

·   Maximum: 5 bar (70 psi)



Production & Capacity

·   Maximum Daily Production: 33 kg (based on the standard model)

·   Maximum Bin Capacity: 12 kg



Dimensions

·   Without Legs (mm): W 386 × D 600 × H 693

·   With Legs (mm): W 386 × D 600 × H 695

About the Brand

SCOTSMAN
Scotsman Ice Systems pioneered the development of affordable, reliable ice-making machines in the 1950s. Over a half a century of research, innovation and superior customer service later, The co. . . read more
Scotsman Ice Systems pioneered the development of affordable, reliable ice-making machines in the 1950s. Over a half a century of research, innovation and superior customer service later, The company remains the largest manufacturer of ice machines in the world with distributors and authorized service agents in over 100 countries. Scotsman understand, better than any other company, the critical importance of ice. read less

Is This For you

Perfect For

  • Cafés and small restaurants
  • Up to 33 kg daily production
  • Crystal-clear gourmet ice cubes
  • Built-in counter installations
  • Compact commercial spaces
  • Moderate beverage service

Not Ideal For

  • High-volume hospitality venues
  • Small home kitchens
  • Portable or outdoor use
  • Locations without water connection
  • Users needing crushed or flake ice
  • Spaces with poor ventilation
desktop-image

Features

The Scotsman ECM57 Self-Contained Ice Machine is a compact commercial ice maker designed to produce clear gourmet ice cubes for cafés, restaurants, offices, hospitality venues, and small foodservice operations. It combines reliable electromechanical controls, durable stainless-steel construction, front ventilation, and an integrated storage bin, making it suitable for businesses that need dependable ice production within a limited installation space.

  • Ideal for Small Commercial Operations

    Designed for cafés, coffee shops, restaurants, office pantries, and hospitality counters that require a steady supply of premium ice without installing a large-capacity machine.

  • Up to 33kg Daily Ice Production

    Produces up to 33kg of ice every 24 hours, depending on operating conditions, and includes a 12kg integrated storage bin to keep ice readily available during service.

  • Crystal-Clear Gourmet Ice Cubes

    Creates individual gourmet-style super cubes designed for attractive beverage presentation, helping improve the appearance of iced coffee, soft drinks, mocktails, and other cold beverages.

  • Built-In Installation Capability

    The air-cooled configuration uses front-panel air intake and exhaust, allowing the machine to be installed beneath counters or within compact commercial work areas while maintaining proper ventilation.

How it compares

Compare with other similar products

Feature

Brand

Product type

Maximum daily production

Integrated storage bin

Ice type

Approximate Cube Weight

Scotsman ECM57 Self Contained Ice Machine 32kg

Scotsman

Narrow self-contained commercial gourmet-cube ice machine

Up to 33kg; title states 32kg

12kg

Gourmet crystal-clear supercube-style ice

Common ECM57 specifications reference approximately 20g for the medium gourmet version; confirm supplied cube configuration

Hoshizaki IM-45CPE Ice Cube Maker 23g – 47kg

Hoshizaki

Mid-capacity self-contained commercial cube ice maker

Up to 47kg

15kg

Large standard cube

23g

Technical Specifications

Complete technical details and specifications

Product & Ice Production

Product Type: Self-Contained Commercial Ice Machine
Model / Reference: ECM 57 AS
Ice Type: Medium Gourmet crystal-clear ice cubes
Cube Weight: Approximately 20 g
Cube Dimensions Ø 30 × H 34 mm
Maximum Ice Production: Up to 33 kg per 24 hours at 10°C ambient / 10°C water
Production at 21°C Ambient / 10°C Water: 31 kg per 24 hours
Production at 32°C Ambient / 21°C Water 25 kg per 24 hours
Internal Storage Capacity: 12 kg

Construction & Cooling

Exterior Material: Stainless steel
Condensing System: Air-cooled
Refrigerant: R290
Installation: Front intake and exhaust airflow supports built-in installation
Condenser Filter: Front-access, removable and washable
Sanitation System: Integrated XSafe automatic sanitation system
Water Protection: Patented anti-scale system
Drainage System: Progressive Water Discharge supports pumping residual water up to 15 m

Dimensions & Electrical

Unit Dimensions: 386 W × 600 D × 695 H mm
Net Weight: 38 kg
Shipping Dimensions: 460 W × 670 D × 810 H mm
Shipping Weight: 45 kg
Voltage / Frequency / Phase: 230 V / 50 Hz / Single Phase
Instant Power: 370 W
Compressor Power: 730 W
Maximum Fuse Size: 10 A

Consumption & Operating Requirements

Energy Consumption: 6.6 kWh per 24 hours
Energy Consumption per 100 kg: 27 kWh
Water Consumption: 4 L per hour
Operating Air Temperature: 10–43°C
Operating Water Temperature: 5–38°C
Required Water Pressure: 1–5 bar
Electrical Voltage Tolerance: −10% to +10%
Legs: Optional and ordered separately
